GL Series aluminum connecting pipe
Key attributes
| Brand | Switchgear parts |
| Model NO. | GL Series aluminum connecting pipe |
| Nominal cross-sectional area | 16mm² |
| Series | GL |
Product descriptions from the supplier
GL series aluminum connecting tube: a reliable choice for power connections
In the field of power transmission and distribution, the stability and efficiency of wire connections are crucial. GL series aluminum connecting pipes, as professional electrical connection accessories, have become an ideal choice for many power projects due to their excellent performance.
Widely applicable scenarios
The GL series aluminum connecting tube is mainly used to achieve reliable connection between aluminum core wires. In overhead power lines, when it is necessary to extend the length of aluminum wires or repair broken parts, GL connecting pipes can ensure a firm connection and ensure continuous and stable current transmission. For example, in the construction of transmission lines in remote mountainous areas, their ease of installation greatly improves construction efficiency. In places such as substations and distribution rooms, the connection between aluminum busbars and aluminum cables also relies on GL series aluminum connection pipes, providing a basic guarantee for the stable operation of power equipment.
Excellent material and advanced craftsmanship
High quality aluminum material: This series of connecting pipes usually uses high-purity 1060 aluminum as the raw material. This aluminum material has excellent conductivity, which can effectively reduce resistance losses during current transmission and improve power transmission efficiency. At the same time, its good ductility enables the connecting tube to tightly adhere to the wire during the crimping process, enhancing the mechanical strength of the connection.
Fine craftsmanship: The manufacturing process adopts advanced extrusion molding technology to ensure that the wall thickness of the connecting pipe is uniform and consistent, and the interior is smooth and flat. This not only facilitates wire insertion, but also reduces the heating phenomenon caused by poor contact. Surface treatment often uses acid washing or anodizing processes to form a dense protective film on the surface of the connecting pipe, significantly improving its corrosion resistance and enabling it to adapt to harsh outdoor environments such as humidity, acidity, and alkalinity, thereby extending its service life.
