Calculate the resonant frequency of an LC circuit using f₀ = 1 / (2π√LC). Essential for designing filters, oscillators, radio tuners, and antenna matching circuits in electronics. This tool calculates the natural resonant frequency (f₀) of an LC circuit — the frequency at which energy oscillates between the inductor’s magnetic field and the capacitor’s electric field. Widely used in RF design, signal filtering, oscillator circuits, and wireless communication systems. What Is the Resonant Frequency of an LC Circuit? The resonant frequency (f₀) is the natural frequency at which an LC circuit oscillates without external input. At this frequency: Inductive reactance (XL ) equals capacitive reactance (XC) Energy continuously transfers between the inductor and capacitor No net reactive power is drawn from the source It is given by the formula: f₀ = 1 / (2 π √(L C)) Where: f₀ = resonant frequency (Hz) L = inductance (H) C = capacitance (F) How Do You Calculate Resonant Frequency from Inductance and Capacitance? Follow these steps: Convert inductance to henrys (H) — e.g., 10 μH = 10 × 10⁻⁶ H Convert capacitance to farads (F) — e.g., 100 pF = 100 × 10⁻¹² F Multiply L and C Take the square root of the product Divide 1 by (2 × π × √(LC)) Example: L = 10 μH = 1e-5 H C = 100 pF = 1e-10 F f₀ = 1 / (2π√(1e-5 × 1e-10)) ≈ 5.03 MHz What Happens at Resonance in an LC Circuit? At resonance: Series LC: Impedance is minimum (ideally zero), current is maximum — used in band-pass filters. Parallel LC: Impedance is maximum, voltage is maximum — used in tank circuits and oscillator feedback loops. Energy sloshes back and forth between L (magnetic field) and C (electric field) with minimal loss. In ideal circuits (no resistance), oscillations continue indefinitely. Is the Resonant Frequency Formula the Same for Series and Parallel LC Circuits? Yes. The resonant frequency formula f₀ = 1 / (2π√LC) applies to both series and parallel LC configurations. However, their impedance behavior differs: Series: low impedance at f₀ Parallel: high impedance at f₀ But the frequency where XL = XC remains identical. What Are Practical Units for L and C in Real Circuits? Because henry (H) and farad (F) are large units, engineers use submultiples: Component Common Units Conversion Inductance (L) μH, mH 1 μH = 10⁻⁶ H 1 mH = 10⁻³ H Capacitance (C) pF, nF, μF 1 pF = 10⁻¹² F 1 nF = 10⁻⁹ F 1 μF = 10⁻⁶ F Typical values: • RF circuits: L = 0.1–100 μH, C = 1–1000 pF → f₀ = kHz to hundreds of MHz • Power electronics: L = mH, C = μF → f₀ = tens to hundreds of Hz How Is LC Resonance Used in Radios and Filters? LC resonance is fundamental in analog electronics: Radio Receivers: Tune to a specific station by adjusting C or L to match the broadcast frequency. Band-Pass Filters: Allow only signals near f₀ to pass (series LC in signal path). Band-Stop (Notch) Filters: Block signals at f₀ using parallel LC. Oscillators: Hartley, Colpitts, and crystal oscillators use LC tanks to set frequency. Antenna Matching: Maximize power transfer by resonating the feed line at operating frequency. Parameter Definitions Parameter Description Inductance (L) Ability to store energy in a magnetic field. Units: H, mH, μH. Example: Ferrite bead = 10 μH. Capacitance (C) Ability to store electric charge. Units: F, μF, nF, pF. Example: Ceramic capacitor = 100 pF. Resonant Frequency (f₀) Natural oscillation frequency in hertz (Hz). Ranges from Hz (power systems) to GHz (microwave circuits). Important Notes Real circuits include resistance (R), causing damping and slight frequency shift. For high-Q circuits (low loss), the ideal formula is highly accurate. Always use consistent SI units (H and F) in calculations. This calculator assumes ideal components; parasitic effects may alter real-world performance. Understanding LC resonance is crucial for anyone working in RF engineering, communications, or analog circuit design.

Calculate the output voltage of a two-resistor voltage divider. Essential for sensor interfacing, ADC scaling, reference voltage generation, and analog circuit design in electronics. This tool calculates the output voltage (Vout) of a two-resistor voltage divider using Ohm's Law and the voltage division principle. Widely used in analog circuits, microcontroller projects, sensor signal conditioning, and power supply design. What Is a Voltage Divider? A voltage divider is a simple circuit that reduces an input voltage (Vin) to a lower output voltage (Vout) using two resistors in series. Resistors R₁ and R₂ are connected end-to-end Vout is taken across R₂ Output voltage is proportional to the ratio of R₂ to total resistance It’s one of the most fundamental building blocks in electronics. How Does a Voltage Divider Work? When two resistors are in series: They share the same current: I = Vin / (R₁ + R₂) Voltage drops across each resistor: V₁ = I × R₁, V₂ = I × R₂ Total voltage: Vin = V₁ + V₂ Output voltage: Vout = V₂ = I × R₂ Substituting I gives the key formula: Vout = Vin × R₂ / (R₁ + R₂) How Do You Calculate Voltage Divider Output? Use the formula: Vout = Vin × R₂ / (R₁ + R₂) Steps: Enter input voltage (Vin) in volts Enter R₁ and R₂ values in ohms Plug into the formula Calculate Vout Example: Vin = 12 V R₁ = 10 kΩ R₂ = 10 kΩ Vout = 12 × 10 / (10 + 10) = 6 V What Is the Formula for Voltage Divider? The standard voltage divider formula is: Vout = Vin × R₂ / (R₁ + R₂) Where: Vout = output voltage (V) Vin = input voltage (V) R₁ = top resistor (Ω) R₂ = bottom resistor (Ω) This assumes no load on the output — ideal for reference or sensing applications. When Should I Use a Voltage Divider? Common applications include: Sensor interfacing: Scale down signals from thermistors, photoresistors, or strain gauges to match ADC range (e.g., 0–5V). Reference voltage generation: Provide stable bias for op-amps, comparators, or microcontrollers. Potentiometer as variable divider: Adjust output voltage manually (e.g., volume control). Level shifting: Convert logic levels between different ICs (e.g., 3.3V → 5V). Teaching circuits: Demonstrate Ohm’s Law and series resistance in classrooms. Why Is a Voltage Divider Not Good for High-Current Loads? A voltage divider has limitations when driving loads: Load affects output: If a load connects to Vout, it forms a parallel path with R₂, reducing effective resistance and changing Vout. Power inefficiency: Resistors dissipate power as heat, especially if R₁ and R₂ are small. Not suitable for high-current applications: Use a regulated voltage source or buffer amplifier instead. For accurate and stable output under load, add a buffer amplifier (e.g., unity-gain op-amp follower). Parameter Definitions Parameter Description Input Voltage (Vin) Total voltage supplied to the circuit. Example: 5 V from a battery or power supply. Output Voltage (Vout) Voltage across R₂, used as reference or signal. Commonly scaled for sensors or microcontrollers. R₁ (Top Resistor) Upper resistor in series chain. Determines how much of Vin drops across it. R₂ (Bottom Resistor) Lower resistor; Vout is measured across this. Higher R₂ → higher Vout. Important Notes Assumes no load on Vout — real-world loading changes results Use high-value resistors (kΩ–MΩ) to minimize current draw For precision applications, use matched resistors or digital potentiometers Always check power dissipation: P = V²/R This calculator provides theoretical values based on ideal conditions. For practical designs, consider loading effects and temperature drift.

Calculate how current splits between two parallel resistors using the current divider rule. Essential for power sharing, shunt sensing, fault analysis, and circuit design in electronics. Find how total current divides between two parallel resistors — no guesswork, just physics. In any parallel branch, **current takes the path of least resistance** — but not all of it. This tool tells you exactly how much flows where. Why Current Divides Inversely with Resistance Unlike voltage dividers (which work in series), current dividers operate in **parallel configurations**, where: All branches see the same voltage But each draws different current based on its resistance Per Ohm’s Law: I = V / R → higher R means lower I So when you split a 10 A supply across a 1 Ω and a 9 Ω resistor, **90% of the current flows through the 1 Ω path** — not half. The Core Rule (For Two Resistors) If total current I enters a node splitting into R₁ and R₂: I₁ = I × R₂ / (R₁ + R₂) → current through R₁ I₂ = I × R₁ / (R₁ + R₂) → current through R₂ Notice: the resistor opposite appears in the numerator. That’s the key to remembering it. Real-World Examples Scenario R₁ R₂ Total I I₁ I₂ Equal resistors 1 kΩ 1 kΩ 2 mA 1 mA 1 mA Unequal loads 100 Ω 400 Ω 500 mA 400 mA 100 mA Near-short condition 0.1 Ω 100 Ω 10 A 9.999 A 0.001 A These numbers explain why a shorted component can hog almost all available current — a critical insight for fuse sizing and fault analysis. Where Engineers Actually Use This This isn’t just textbook theory. The current divider principle shows up in: Power rail sharing: How current distributes among parallel ICs or LEDs Shunt-based current sensing: A small resistor (shunt) diverts a known fraction of current for measurement Bias networks: Setting base current in BJT circuits using parallel paths Fault tolerance design: Predicting current redistribution if one branch fails open Thermal management: Identifying which resistor dissipates more power (P = I²R) Common Pitfalls to Avoid Assuming equal current split just because components look similar Ignoring that adding a load changes the effective R₂ — use this rule only for unloaded branches Applying the formula to non-resistive or reactive (AC) circuits without impedance conversion Tip: For complex networks, reduce them to an equivalent two-branch model first. Parameters Explained Total Input Current (I) The current arriving at the junction before splitting — measured in amperes (A). I₁, I₂ Branch currents. Their sum always equals I (Kirchhoff’s Current Law). R₁, R₂ Resistances in each parallel arm. Even small differences cause large current imbalances. Remember This “In parallel, voltage is shared, but current is selfish — it favors the easier path.” Use this calculator to design smarter, safer, and more efficient circuits.

Calculate inductive reactance (XL), capacitive reactance (XC), inductance (L), capacitance (C), or frequency (f) using AC circuit formulas. Ideal for filter design, resonance analysis, and component selection. Why does an inductor block high frequencies? Why does a capacitor pass them? The answer lies in reactance — the frequency-dependent opposition to AC current. Two Types of Reactance Unlike resistance, reactance doesn’t dissipate energy. It stores it — and its value changes with frequency: Type Formula Phase Shift Frequency Response Inductive Reactance (XL) XL = 2πfL Current lags voltage by 90° ↑ as frequency ↑ Capacitive Reactance (XC) XC = 1 / (2πfC) Current leads voltage by 90° ↓ as frequency ↑ Key Parameters Explained Frequency (f) AC cycles per second (Hz). Standard power: 50 Hz (Europe/Asia), 60 Hz (North America). RF circuits use kHz–GHz. Inductance (L) Ability to store energy in a magnetic field. Units: Henry (H) – theoretical Millihenry (mH) = 10⁻³ H Microhenry (μH) = 10⁻⁶ H – common in filters Capacitance (C) Ability to store electric charge. Units: Farad (F) – huge unit Microfarad (μF) = 10⁻⁶ F – power supplies Nanofarad (nF) = 10⁻⁹ F, Picofarad (pF) = 10⁻¹² F – RF tuning Real Engineering Use Cases LC Filters: Combine L and C to pass or block specific frequencies (e.g., audio crossovers, EMI filters). Resonant Circuits: At resonance, XL = XC → circuit becomes purely resistive. Used in radios and wireless charging. Power Factor Correction: Add capacitors to offset inductive lag from motors, reducing wasted current. Signal Coupling: Capacitors block DC but pass AC — choose C so XC is low at operating frequency. Troubleshooting: Unexpected motor overheating? Check if reactive current is too high due to uncorrected XL. Quick Calculation Examples Scenario f L or C Reactance Power line choke 60 Hz 10 mH XL ≈ 3.77 Ω RF bypass cap 100 MHz 100 pF XC ≈ 15.9 Ω Audio coupling 20 Hz 10 μF XC ≈ 796 Ω Remember This “Inductors resist change in current. Capacitors resist change in voltage. In AC, everything is changing — constantly.” Use this calculator to predict how your circuit behaves across frequencies — before you build it.

Calculate required capacitor capacity (kVAR) for power factor correction. Improve efficiency, reduce energy loss, and lower utility bills in industrial and commercial systems with inductive loads like motors and transformers. Why pay for reactive power? Fix low power factor with capacitors — save energy, reduce current, and avoid penalties. In industrial plants, motors and transformers draw not just real power (kW), but also reactive power (kVAR). This causes higher currents, voltage drops, and wasted energy — even though no useful work is done. Power factor correction (PFC) adds capacitors to offset inductive loads, improving efficiency and cutting costs. What Is Power Factor? Power factor (PF) is the ratio of real power (kW) to apparent power (kVA): PF = kW / kVA A PF of 0.7 means only 70% of the current is doing useful work — the rest is “wasted” as reactive current. Why Correct It? High current → larger conductors, more heat, higher losses Voltage drop → equipment underperformance Utility penalties → many providers charge extra for PF < 0.9 Overloaded transformers and cables → reduced lifespan By adding capacitors, you cancel out reactive power — reducing total current and boosting efficiency. The Core Formula The required reactive power compensation (Qc) is: Q c = P × (tanφ₁ - tanφ₂) Where: P = Active load power (kW) φ₁ = Initial phase angle (cosφ₁ = initial PF) φ₂ = Target phase angle (cosφ₂ = desired PF) Example: A 100 kW motor at PF = 0.7 needs ~58 kVAR of capacitance to reach PF = 0.95. Key Parameters Explained Voltage System operating voltage: Single-phase: Phase-to-neutral voltage (e.g., 230 V) Three-phase: Line-to-line voltage (e.g., 400 V, 415 V) Frequency AC cycle rate: typically 50 Hz (Europe/Asia) or 60 Hz (North America). Load (kW) Real power consumed by inductive equipment (motors, pumps, compressors). Current Power Factor Existing PF value (0–1). Common values: 0.5–0.8 in old plants; 0.8–0.9 in modern facilities. Desired Power Factor Target PF after correction. Recommended: ≥ 0.95. Avoid over-correction (>1.0) — can cause resonance or voltage rise. Capacitor Voltage Rated voltage of capacitor bank. Must match system voltage (e.g., 400V, 415V). Use derating if ambient temperature is high. Connection Type Determines how capacitors are wired: Star (Y): Used in high-voltage or balanced three-phase systems Delta (Δ): Common in low-voltage applications; handles higher current Application Scenarios Industrial Plants: Motors on production lines often run at PF < 0.7 Commercial Buildings: HVAC systems, elevators, lighting ballasts Data Centers: UPS systems and cooling fans generate reactive load Manufacturing: Welding machines, conveyor drives, compressors Renewable Integration: Solar inverters may need PFC support Pro Tips from Engineers Use automatic switching banks — adjust capacitance based on load variation Size capacitors in steps (e.g., 10 kVAR, 20 kVAR) for dynamic control Monitor harmonics — capacitors can amplify harmonic distortion Combine with power quality analyzers for real-time data Quick Reference Table Initial PF Target PF Required Qc (kVAR) Impact 0.5 0.8 1.1 kVAR/kW High improvement 0.7 0.95 0.6 kVAR/kW Typical industrial upgrade 0.8 0.95 0.3 kVAR/kW Fine-tuning Remember This “You don’t pay for kW — but you do pay for kVA. Fix your power factor, and you’ll see lower bills and longer equipment life.” Use this calculator to plan efficient, safe, and cost-effective power factor correction projects.

Calculate AC circuit impedance (Z) using Z = √(R² + X²). Understand how resistance and reactance combine in series or parallel circuits. Essential for engineers, students, and technicians working with RLC systems. What’s the total opposition in an AC circuit? It's not just resistance — it’s impedance. In DC, we use resistance (R). But in AC, things get more interesting: inductors and capacitors add reactance (X), which changes with frequency. Impedance (Z) is the vector sum of resistance and reactance: Z = √(R² + X²) This formula applies to both series and parallel configurations — but only when you know the total R and X. Why Impedance Matters High impedance → low current flow, even if voltage is high Low impedance → high current, risk of overload Proper impedance matching → maximum power transfer (e.g., antennas, audio systems) Critical for designing filters, amplifiers, and resonant circuits Resistance vs Reactance Parameter Definition Energy Behavior Resistance (R) Opposition from conductive materials (e.g., wires, resistors) Dissipates energy as heat Reactance (X) Opposition from inductors (XL) or capacitors (XC) Stores and releases energy (magnetic/electric field) The Impedance Formula Explained Impedance is a complex quantity: $ Z = R + jX $, where: R = real part (resistance) X = imaginary part (reactance) j = imaginary unit (√(-1)) The magnitude is: $ |Z| = \sqrt{R^2 + X^2} $ Example: A circuit with R = 20 Ω and X = 10 Ω has: Z = √(20² + 10²) = √500 ≈ 22.36 Ω Connection Types Matter Use this calculator for both series and parallel connections — but remember: Series: Total R = R₁ + R₂, Total X = X₁ + X₂ Parallel: Use admittance (Y = 1/Z) or convert to equivalent R and X first Note: This tool assumes you’ve already calculated total R and X. Real-World Applications Audio Systems: Match speaker impedance to amplifier output for best performance RF Engineering: Tune antennas and transmission lines to minimize reflection Power Electronics: Design inverters and converters with proper load impedance Filter Design: Set cutoff frequencies using known Z values Resonance Analysis: At resonance, X = 0 → Z = R → maximum current Quick Reference Table Scenario R (Ω) X (Ω) Z (Ω) Purely resistive 10 0 10 Inductive load 5 12 13 Capacitive load 8 6 10 Remember This “Resistance dissipates energy. Reactance stores it. Impedance combines them — and determines how much current flows in an AC circuit.” Use this calculator to quickly find total impedance without manual math — perfect for quick checks during design or troubleshooting.

Calculate actual reactive power (kVAR) of a capacitor under non-rated voltage and frequency conditions. Understand how voltage fluctuations affect performance, lifespan, and safety in industrial power systems. Why does your 100 kVAR capacitor deliver only 90 kVAR? The answer lies in voltage and frequency. In real-world power systems, capacitors often operate at voltages different from their rated values. For example: A 400 V capacitor used in a 380 V system → delivers less than rated kVAR A 400 V capacitor used in a 415 V system → outputs more than rated kVAR This tool calculates the actual reactive power output based on: - Operating voltage - Supply frequency - Capacitor's rated specs The Core Formula Q actual = Q rated × (U in / U rated)² × (f supply / f rated) Where: Symbol Calculator Field Description Unit Qactual — Actual reactive power output kVAR (or VAR) Qrated Rated Reactive Power Capacitor's nominal reactive power rating kVAR Uin Input Voltage Actual system operating voltage V Urated Rated Voltage Voltage marked on capacitor nameplate V fsupply Supply Frequency Network operating frequency Hz frated Rated Frequency Design frequency of the capacitor Hz Key Insight: Reactive power is proportional to the square of voltage. A 10% increase in voltage → ~21% higher reactive power A 5% decrease in voltage → ~10% lower reactive power Real-World Example Consider a 100 kVAR capacitor rated for 400 V, 50 Hz: Used in a 380 V system → Qactual ≈ 100 × (380/400)² = 90.25 kVAR Used in a 415 V system → Qactual ≈ 100 × (415/400)² = 107.6 kVAR Even small deviations can lead to significant differences — especially critical in precision applications. Why This Matters Under-voltage → insufficient reactive power → poor PF correction Over-voltage → excessive reactive power → risk of overcompensation, resonance, or insulation failure Long-term overvoltage reduces capacitor lifespan Voltage fluctuations cause dynamic changes in kVAR output Parameter Definitions Input Voltage (Uin) Actual operating voltage of the network (e.g., 380 V, 400 V, 415 V). Must be within ±10% of rated voltage for safe operation. Supply Frequency (fsupply) Operating frequency of the system (typically 50 Hz or 60 Hz). Deviations affect capacitance behavior. Capacitor Rated Power (Qrated) Nominal reactive power specified on the nameplate (e.g., 100 kVAR). Capacitor Rated Voltage (Urated) Maximum voltage the capacitor is designed to handle safely. Common ratings: 400 V, 415 V, 440 V. Capacitor Rated Frequency (frated) Design frequency (usually 50 Hz or 60 Hz). If mismatched, affects current and heating. Application Scenarios Industrial Substations: Verify capacitor bank performance under varying load conditions Capacitor Selection: Ensure chosen capacitors provide enough kVAR at minimum system voltage Voltage Fluctuation Analysis: Model how daily voltage swings impact PF correction Lifespan Evaluation: Assess whether long-term overvoltage will shorten capacitor life Dynamic Compensation: Use with automatic switching banks to adjust kVAR output Pro Tips from Engineers Always select capacitors with rated voltage higher than system voltage (e.g., 400 V for 380 V system) Use step-controlled capacitor banks to avoid overcompensation Combine with power factor controllers for real-time monitoring Avoid long-term operation above rated voltage — causes overheating and dielectric breakdown Monitor harmonics — capacitors can amplify harmonic currents if not properly tuned Quick Reference Table Voltage Ratio Power Factor Adjustment Effect on kVAR 0.95 (380V/400V) -10% ~90% of rated kVAR 1.00 (400V/400V) 0% 100% of rated kVAR 1.05 (420V/400V) +10% ~110% of rated kVAR Remember This “A capacitor doesn’t just deliver its rated kVAR — it delivers what the voltage tells it to. Watch the voltage, or you’ll get surprised by the current.” Use this calculator to ensure your capacitor bank performs as expected — even when the grid isn’t perfect.

This tool calculates the grounding resistance of an earthing system based on soil resistivity, electrode type, and geometric parameters. It helps verify compliance with IEC 60364-4-41 for coordination between earth electrodes and residual current devices (RCBOs). The calculated resistance is compared to the safety voltage limit (typically 50 V or 25 V) to ensure safe operation and proper tripping of protective devices. Input Parameters Explained Parameter Description Typical Values / Notes Type of Ground Electrode Physical configuration of the earthing conductor Rod, Horizontal rope, Ring, Mesh network Soil Type Determines soil resistivity (ρ) Agricultural (10–150 Ω·m), Clay (50–200 Ω·m), Rocky (1500–10000 Ω·m), etc. Quantity (n) Number of identical parallel electrodes Must be ≥1; affects total resistance via parallel reduction Length (L) Total buried conductor length Rod: depth; Rope: linear length; Ring: circumference; Mesh: sum of all conductors Resistivity (ρ) Soil's electrical resistivity Measured in Ω·m; use field measurement or typical values Safety Voltage (U₀) Maximum permissible touch voltage 50 V (dry), 25 V (wet/high-risk) Application Scenarios Residential & Commercial Installations: Verify that single rod or ring electrodes meet touch voltage limits in TT or TN systems. Industrial Earthing Systems: Design mesh networks for substations, factories, or data centers with low-resistance requirements. RCBO Coordination Checks: Ensure grounding resistance is low enough to allow reliable tripping of 30 mA, 100 mA, or higher sensitivity devices. Site Feasibility Studies: Estimate earthing performance during early design stages using typical soil resistivity values. Safety Audits & Compliance Testing: Validate existing installations against IEC 60364-4-41 and local electrical codes. Who Should Use This Tool? Electrical designers and consulting engineers Contractors installing earthing systems Facility maintenance teams performing periodic testing Safety inspectors verifying regulatory compliance Students learning about grounding, fault currents, and electric shock protection Frequently Asked Questions (FAQ) Why must grounding resistance be low? A low grounding resistance ensures that during an earth fault, sufficient current flows to trip the protective device quickly. More importantly, it limits the touch voltage (V = I × R) to a safe level—typically ≤50 V in dry areas or ≤25 V in wet locations. How does soil type affect grounding? Soil resistivity (ρ) directly impacts grounding resistance. Rocky or sandy soils have high ρ (up to 10,000 Ω·m), leading to poor conductivity and high resistance. Clay or moist agricultural soils have low ρ (10–150 Ω·m), making them ideal for earthing. What if my calculated resistance is too high? You can: (1) increase electrode length or depth, (2) add more parallel rods, (3) use conductive backfill (e.g., bentonite), (4) install a ring or mesh network, or (5) treat the soil to reduce resistivity. Does the number of electrodes always reduce resistance proportionally? No. Due to mutual coupling, adding a second rod typically reduces resistance by only 30–40%, not 50%. The spacing between electrodes must be ≥ twice the rod length to achieve near-ideal parallel reduction. How do I know if my system complies with IEC 60364-4-41? Check that R ≤ U₀ / IΔn, where U₀ is the safety voltage (50 V or 25 V) and IΔn is the RCBO’s rated residual current (e.g., 0.03 A). For example, with a 30 mA RCBO and 50 V limit, R must be ≤ 1667 Ω—which is almost always satisfied. The real challenge is achieving low enough R for high-sensitivity or high-current systems. Key Compliance Check To comply with IEC 60364-4-41, your grounding system must satisfy: R ≤ U₀ / IΔn Where: • R = Calculated grounding resistance (Ω) • U₀ = Safety voltage (50 V or 25 V) • IΔn = Rated residual operating current of the RCD/RCBO (e.g., 0.03 A for 30 mA) Typical Grounding Resistance Targets Residential TT system: ≤ 100 Ω (for 30 mA RCD) Industrial substation: ≤ 1–5 Ω Lightning protection: ≤ 10 Ω Telecom/data center: ≤ 1 Ω Tip: Always validate critical installations with on-site soil resistivity measurements (e.g., Wenner four-point method) rather than relying solely on typical values.

Calculate equivalent capacitance for capacitors in series or parallel. Supports µF, nF, pF. Useful for circuit design, filter tuning, and electronics education. When You Need This Calculation Designing a low-pass filter using multiple capacitors Creating a custom capacitance value when exact part is unavailable Building a power supply decoupling network Teaching students about series and parallel circuits Repairing vintage audio equipment with obsolete components How Equivalent Capacitance Is Calculated Series Connection In a series connection, the total capacitance is given by: 1/C_eq = 1/C₁ + 1/C₂ + ... + 1/Cₙ Key points: Total capacitance is always less than the smallest individual capacitor Used to increase voltage rating (voltage divides across capacitors) Common in high-voltage applications Parallel Connection In a parallel connection, the total capacitance is simply the sum: C_eq = C₁ + C₂ + ... + Cₙ Key points: Total capacitance is greater than any single capacitor Used to increase energy storage or reduce ESR Ideal for bypass and decoupling circuits Note: The calculator handles both cases automatically based on your selection. Unit Support The tool supports automatic conversion between common units: Farad (F) — base unit Microfarad (µF) = 10⁻⁶ F Nanofarad (nF) = 10⁻⁹ F Picofarad (pF) = 10⁻¹² F Just enter the value with its unit (e.g., 10µF, 220nF, 100pF), and the calculator will normalize them before computation. Industry-Specific Applications Field Use Case Why It Matters Audio Engineering Designing tone controls or crossover networks Combining capacitors allows precise frequency response shaping Power Electronics Decoupling capacitors in switching power supplies Parallel capacitors reduce impedance at high frequencies RF Circuits Tuning circuits with variable capacitance Series combinations allow fine-tuning of resonant frequency Education Teaching Ohm's Law and Kirchhoff's laws Visualizing how components combine in circuits DIY Projects Building simple oscillators or timers Custom capacitance values enable unique circuit behavior Frequently Asked Questions How do I calculate total capacitance in series? For capacitors in series: 1/C_eq = 1/C₁ + 1/C₂ + ... + 1/Cₙ. The total capacitance is always less than the smallest individual capacitor. What is the formula for parallel capacitors? For capacitors in parallel: C_eq = C₁ + C₂ + ... + Cₙ. The total capacitance is the sum of all individual values. Can I use different units like µF and nF? Yes! The calculator automatically converts between µF, nF, and pF. Just enter the value with its unit, and it will be normalized before calculation. Why is this useful in real circuits? In practice, you may not have a capacitor with the exact value needed. By combining smaller ones in series or parallel, you can achieve the desired capacitance for filters, timing circuits, or power supply decoupling.

This tool calculates the equivalent resistance of several resistors connected either in series or in parallel. Enter each resistor value with its unit (Ω, kΩ, or MΩ), and the calculator will apply the correct formula automatically. How It Works Resistors in Series When resistors are connected end-to-end (in series), their resistances add up: Req = R₁ + R₂ + ... + Rₙ The total resistance is always greater than any individual resistor. Resistors in Parallel When resistors share the same two nodes (in parallel), the reciprocal of the total resistance equals the sum of the reciprocals: 1/Req = 1/R₁ + 1/R₂ + ... + 1/Rₙ The total resistance is always less than the smallest individual resistor. Supported Units Ohm (Ω) Kiloohm (kΩ) = 1,000 Ω Megaohm (MΩ) = 1,000,000 Ω You can mix units—e.g., enter "1k", "470", and "2.2M"—and the calculator will convert them correctly. Common Applications Voltage divider circuits: Combine two resistors to scale down a voltage. Current limiting: Use a series resistor to protect LEDs or sensors. Pull-up/pull-down networks: Set default logic levels in digital circuits. Impedance matching: Adjust total resistance for signal integrity. Educational labs: Teach Ohm’s Law and Kirchhoff’s laws. Example Calculations Configuration Resistor Values Equivalent Resistance Series 100 Ω, 200 Ω, 300 Ω 600 Ω Parallel 1 kΩ, 1 kΩ 500 Ω Parallel 10 kΩ, 10 kΩ, 10 kΩ ≈3.33 kΩ Frequently Asked Questions Can I use this for more than 10 resistors? Yes. Most implementations allow you to add as many resistors as needed—the formulas work for any number of components. Why is parallel resistance lower than individual values? Because current has multiple paths to flow through. More paths mean less overall opposition to current—hence lower total resistance. What if I enter an invalid value like "abc"? The calculator will typically ignore non-numeric inputs or show an error. Always use numbers followed by optional unit symbols (e.g., 4.7k, 100, 2M).
