What are the steps and precautions for retrofitting substation microcomputer protection devices?

Retrofitting microcomputer protection devices in substations should follow specific steps and precautions. A possible retrofit plan is as follows:

• Investigate the current status: Understand the types, specifications, operating conditions, and existing issues of the microcomputer protection devices in the substation to provide a basis for the retrofit.

• Develop a retrofit plan: Based on the investigation and requirements, create a detailed plan including specific tasks, technical specifications, implementation steps, and safety measures.

• Prepare necessary tools and equipment: Gather required tools and equipment according to the plan, such as new protection devices, test instruments, and wiring tools.

• Implement the retrofit: Carry out device replacement, commissioning, and testing according to the plan to ensure smooth execution.

• Conduct acceptance testing: After completion, perform acceptance tests to verify that the new devices operate correctly and meet technical requirements.

• Remove old devices: Once the new devices are operational, dismantle the old equipment and clean the work area.

Key precautions during the retrofit:

• Ensure safety: Apply necessary safety measures throughout the process to protect personnel.

• Guarantee quality: Maintain high work quality to ensure reliable operation of the new devices.

• Backup existing devices: Back up settings and data from the original devices before retrofitting to prevent data loss.

• Document and report: Record all procedures and results during the retrofit and report to supervisors for future maintenance and management.

In summary, retrofitting microcomputer protection devices in substations is a critical task that requires careful planning and proper execution to ensure safe and stable power system operation.
