DNH18 Series Strip Fuse Disconnector
Zhejiang Wone IT Service Co., Ltd...
1yrs +
staff 1000+m² US$300000000+
Key attributes
| Brand | Switchgear parts |
| Model NO. | DNH18 Series Strip Fuse Disconnector |
| Rated normal current | 630A |
| Rated frequency | 50/60Hz |
| number of poles | 3P |
| Series | DNH18 |
Product descriptions from the supplier
Description
DNH18 strip fuse type isolation switch, specially designed for industrial distribution systems, with both isolation switch and fuse protection functions, suitable for breaking and overload protection of three-phase AC circuits
Fuse Disconnector General Model List
|
Serial number |
Order No | Electric current |
Adaptation |
|
1 |
DNH18-160/3L | 160A | Fixed installation (punching), three-phase synchronous operation, with fuse |
|
2 |
DNH18-160/311L | 160A | Hook up installation, with auxiliary contact, three-phase synchronous operation, with fuse |
|
3 |
DNH18-250/3L | 250A | Fixed installation (punching), three-phase synchronous operation, with fuse |
|
4 |
DNH18-250/3S | 250A | Fixed installation (punching), three-phase independent operation, with fuse |
|
5 |
DNH18-250/3LD | 250A | Fixed installation (punching), three-phase synchronous operation, with isolating knife |
|
6 |
DNH18-250/311L | 250A | Hook up installation, with auxiliary contact, three-phase synchronous operation, with fuse |
|
7 |
DNH18-400/3L | 400A | Fixed installation (punching), three-phase synchronous operation, with fuse |
| 8 | DNH18-400/3S | 400A | Fixed installation (punching), three-phase independent operation, with fuse |
|
9 |
DNH18-400/3LD | 400A | A fixed installation (punching), three-phase synchronous operation, with isolating knife |
|
10 |
DNH18-400/311L | 400A | Hook up installation, with auxiliary contact, three-phase synchronous operation, with fuse |
|
11 |
DNH18-630/3L | 630A | Fixed installation (punching), three-phase synchronous operation, with fuse |
|
12 |
DNH18-630/3S | 630A | Fixed installation (punching), three-phase independent operation, with fuse |
|
13 |
DNH18-630/3LD | 630A | Fixed installation (punching), three-phase synchronous operation, with isolating knife |
|
14 |
DNH18-630/311L | 630A | Hook up installation, with auxiliary contact, three-phase synchronous operation, with fuse |
|
Remarks |
1. For other specific order models, please see the explanation of the model of the bar fuse disconnector | ||
| 2. If you need other accessories, such as wiring terminals, please check the accessories list of strip fuse disconnector | |||
Fuse Disconnector Technical Parameter
|
DNN18-160 |
DNN18-250 | DNN18-400 |
DNN18-630 |
|||||||||||||
|
Electrical parameters |
With fuse | Rated working voltage | Ue | V | AC
400 |
AC
500 |
AC
690 |
AC
400 |
AC
500 |
AC
690 |
AC
400 |
AC
500 |
AC
690 |
AC
400 |
AC
500 |
AC 690 |
|
|
Rated working current | Ie | A | 160 | 125 | 100 | 250 | 250 | 200 | 400 | 400 | 315 | 630 | 630 |
630 |
|
|
Agreed heating current |
Ith | A | 160 | 125 | 100 | 250 | 250 | 200 | 400 | 400 | 315 | 630 | 630 |
630 |
||
|
Service level |
AC-23B | AC-23B | AC-22B | AC-23B | AC-22B | AC-21B | AC-23B | AC-22B | AC-21B | AC-23B | AC-22B |
AC-21B |
||||
|
Rated limiting short-circuit current |
Iq | kA | 50 | 100 | 100 | 50 | 100 | 100 | 50 | 100 | 100 |
50 |
||||
|
|
Rated insulation voltage | Ui | V | 1000 | 1000 | 1000 |
1000 |
|||||||||
|
Rated impulse withstand voltage |
Uimp | kV | 8 | 12 | 12 |
12 |
||||||||||
|
|
Rated frequency | Hz | 50/60 | 50/60 | 50/60 |
50/60 |
||||||||||
|
Electric life times |
time | 200 | 200 | 200 |
200 |
|||||||||||
|
With isolating knife |
Rated working voltage | Ue | V | \ | \ | AC500 | \ | \ | AC500 | \ | \ | AC500 |
\ |
|||
|
Rated working current |
Ie | A | \ | \ | 250 | \ | \ | 400 | \ | \ | 630 | \ | ||||
|
Agreed heating current |
Ith | A | \ | \ | 250 | \ | \ | 400 | \ | \ | 630 |
\ |
||||
|
Service level |
\ | \ | AC-23B | \ | \ | AC-23B | \ | \ | AC-23B | \ | ||||||
|
|
Rated limiting short-circuit current | Iq | kA | \ | \ | 12 | \ | \ | 12 | \ | \ | 12 |
\ |
|||
|
Rated insulation voltage |
Ui | V | \ | 100 | 1000 |
1000 |
||||||||||
|
|
Rated impulse withstand voltage | Uimp | kV | \ | 12 | 12 |
12 |
|||||||||
|
Rated frequency |
Hz | \ | 50\60 | 50\60 |
50\60 |
|||||||||||
|
|
Electric life times | time | \ | 200 | 200 |
200 |
||||||||||
|
Fuse |
Size （RT16/NT/NH）
GB/T13539.2 IEC 62269-2 |
00 | 1 | 2 |
3 |
|||||||||||
|
|
Working current | In | A | 160 | 125 | 100 | 250 | 250 | 200 | 400 | 400 | 315 | 630 | 630 |
500 |
|
|
power waste |
P | W | 12 | 12 | 12 | 18 | 23 | 32 | 28 | 34 | 45 | 40 | 48 |
60 |
||
|
Mechanism |
Mechanical life | time | 1400 | 1400 | 800 | 800 | 1400 |
800 |
||||||||
|
Busbar spacing |
mm | 185 | 185 | 185 |
185 |
|||||||||||
|
Protection grade of mechanism |
Front
|
on | IP20 | IP20 | IP20 |
IP20 |
||||||||||
|
off |
IP30 | IP30 | IP30 |
IP30 |
||||||||||||
|
Other
|
Electronic fuse monitor (EFM) | Can be added | Can be added | Can be added |
Can be added |
|||||||||||
|
Switch opening and closing signal feedback (microswitch) |
Can be added | Can be added | Can be added | Can be added | ||||||||||||
|
Working conditions
|
Ambient air temperature | ℃ |
-5 ～ +55 |
|||||||||||||
|
Rated working system |
Uninterrupted working system | |||||||||||||||
|
Operation mode |
Handle operation |
|||||||||||||||
|
Installation method |
Vertical installation |
|||||||||||||||
|
Altitude |
m |
≤ 2000 |
||||||||||||||
|
class of pollution |
3 |
|||||||||||||||
|
Overvoltage level |
Overvoltage level | Ⅲ
|
Ⅳ |
|||||||||||||
Fuse Disconnector Outline and Installation Dimension (mm)
