Commercial Integrated Rectifier Stack
Key attributes
| Brand | RW Energy |
| Model NO. | Commercial Integrated Rectifier Stack |
| Rated voltage | 3*230(400)V |
| Rated normal current | 4000A |
| Rated Output Rating | 1200kW |
| Series | WZ12Z |
Product descriptions from the supplier
Product Overview
Tailored for large public charging stations, commercial parking clusters, auto test bases, gas station energy hubs, and government/enterprise charging hubs, this rectifier stack offers 480kW/960kW/1200kW specs. It supports 12 single-gun or 6 dual-gun terminals, enabling 12 vehicles to charge simultaneously. Compatible with CCCP 1.6J (standalone/commercial use), it has standard RFID + optional credit card payment. IP54/IK10 protection and -30℃~55℃ operating temperature ensure stable outdoor operation, with integrated design for easy installation and maintenance.
Key Features
Flexible Terminal Configuration: 12 single-gun or 6 dual-gun options, adapting to diverse parking and service modes.
12-Vehicle Concurrent Charging: Boosts charging station throughput for high-traffic scenarios.
Parallel Output: Optional 40kW per port, balancing power distribution to avoid monopolization.
Configurable Power: Adjusts based on grid load and battery states, ensuring economic operation.
Dual-Mode Support: Standalone (internal management) and commercial (platform connection) modes.
Full-Vehicle Compatibility: 200-1000VDC voltage, 1200A max current, suitable for passenger cars, trucks, etc.
Diversified Payment: Standard RFID + optional credit card reader, meeting commercial needs.
High Protection: IP54 dustproof/waterproof + IK10 impact resistance for harsh outdoor environments.
Comprehensive Safety: Overvoltage/lightning/overcurrent/leakage protection + emergency stop button.
Technical Parameters
Category |
specifications |
Data parameters |
|
Appearance structure |
Dimensions (L x D x H) |
1500mm x 800mm x 1850mm |
1900mm x 900mm x 1950mm |
Weight |
550kg |
750kg |
|
Maximum carrying capacity |
6 dual gun charging stations or 12 single gun charging stations |
||
Parallel Charge Mode (Optional) |
40kW per Port |
||
Electrical indicators |
Input Voltage |
400VAC / 480VAC (3P+N+PE) |
|
Input frequency |
50/60Hz |
||
Output Voltage |
200 - 1000VDC |
||
Output current |
0 to 1200A |
0 to 4000A |
|
rated power |
480kW |
960kW/1200kW |
|
Efficiency |
≥94% at nominal output power |
||
Power factor |
> 0.98 |
||
Communication protocol |
CCCP 1.6J |
||
functional design |
Display |
Customize according to requirement |
|
RFID system |
ISO/IEC 14443A/B |
||
Access Control |
RFID: ISO/IEC 14443A/B / Credit Card Reader (Optional) |
||
Communication |
Ethernet - Standard | 3G/4G Modem (Optional) |
||
Power Electronics Cooling |
Air Cooled |
||
work environment |
Operating temperature |
-30℃ to 55℃ |
|
Working/ Storage Humidity |
≤ 95% RH/≤ 99% RH (Non-condensing) |
||
Altitude |
< 2000m |
||
Ingress Protection |
IP54/ IK10 |
||
safety design |
Safety standard |
GB/T 18487, GB/T 20234, GB/T 27930, ISO15118, IEC61851 |
|
Safety protection |
Overvoltage protection, lightning protection, overcurrent protection, leakage protection, waterproof protection, etc. |
||
Emergency Stop |
Emergency Stop Button Disables Output Power |
||
Application Scenarios
Large Public Charging Stations: 960kW/1200kW version for high traffic; 12-vehicle concurrent charging reduces queuing.
Commercial Parking Clusters: 480kW version with flexible terminal configuration; convenient self-service payment.
Auto Test/Delivery Centers: 960kW/1200kW version for multiple vehicles; configurable power adapts to test scenarios.
Gas Station Energy Hubs: 480kW/960kW version, compact design fits outdoor environment; enriches services.
Government/Enterprise Charging Hubs: 480kW/960kW version, standalone/commercial modes for internal/public use.
Public Transport Terminals: 1200kW version for buses/sanitation vehicles; high current shortens charging time.
1. Only as an additional service, not for profit purposes: For scenarios such as hotels/homestays, beauty salons, etc., it is recommended to use a light asset model and deploy a small amount of WZ15L, WZ15W, or WZ17W for charging settlement through local pricing models, in order to provide additional value-added services.
2. Scenarios for small commercial charging stations/shopping mall charging stations: Considering the load capacity of the station area, it is not possible to deploy too many charging positions. WZ05, WZ06, WZ07, WZ08, and other fast charging devices with one machine and two guns can be selected, which are the preferred choices for the renovation of old parking lots. They can be easily deployed and used. If you need a scenario with one machine and multiple positions, you can choose the WZ09 and WZ10 series.
3. Medium to large commercial charging station scenarios: Choose multiple integrated one machine dual gun high-power solutions, such as WZ06, WZ07, WZ08, WZ09, WZ10 series, or a set of WZ12 series, to meet the simultaneous charging of multiple vehicles.
4. Large and ultra large commercial charging scenarios: Choose the WZ12 series, equipped with a large number of fast charging terminals and a small number of liquid cooled charging terminals. Firstly, it can meet the ultra fast charging needs of some high-end car models, demonstrating operational strength and improving reputation. Secondly, it can meet the simultaneous charging needs of many vehicles through a large number of fast charging terminals.
Peak efficiency ≥ 96%; The power factor is all>0.98, with low energy loss.
The entire system supports intelligent power regulation, which can dynamically allocate power based on grid load and battery status, avoiding grid overload and reducing operating costs.
