Oil-immersed amorphous alloy distribution transformer
Key attributes
| Brand | ROCKWILL |
| Model NO. | Oil-immersed amorphous alloy distribution transformer |
| Rated voltage | 35kV |
| Rated frequency | 50/60Hz |
| Rated capacity | 1000kVA |
| Series | SH15 |
Product descriptions from the supplier
Product Introduction
The oil-immersed amorphous amorphous alloy amorphous alloy distribution transformer uses amorphous alloy materials for its core, featuring extremely low no-load loss and no-load current, providing efficient and low-energy-consumption power transmission. The oil-immersed design utilizes transformer oil as a cooling medium, which can effectively dissipate heat and improve the operational stability of the transformer. This transformer has relatively low temperature rise and noise, extending the service life of the equipment, and is particularly suitable for long-term operation in power distribution applications.
Scope of Application
Oil-immersed amorphous alloy distribution transformers are widely used in urban and rural power distribution systems, especially suitable for places with high requirements for high efficiency, energy saving and long-term stable operation. They are extensively applied in industrial enterprises (such as metallurgy, chemical industry, mining, etc.), urban high-rise buildings, commercial areas, transportation infrastructure (such as subways, airports, stations) and other public facilities that require stable power supply.
Product Description
Main parameters
Rated capacity |
10 kVA ~ 5000 kVA |
Rated input voltage |
10 kV, 35 kV, 110 kV |
Rated output voltage |
400 V, 230 V |
The decline in no - load losses |
70% - 80% |
The no - load current decreased |
About 85% |
Executive Standards
IEC 60076 series |
Suitable for all types of power transformers |
GB/T 1094 series |
China Power Transformer Standard |
GB/T 18655 |
Special requirements for amorphous alloy transformers are specified |
GB 4208 |
Specify the protection level of the transformer's shell |
GB/T 2820 |
Limit the noise emission of the transformer |
